- Point-and-Shoot scanning
- Follows the ISO15416 and ANSI X3.182 Bar Code Inspection Method (Decodability only)
- Auto-discriminates between all popular symbologies
- Multiple scan averaging
- Traditional analysis also provided
Quick Check are easy to use, yet packed with high performance features that utilize the most sophisticated test methods. All the popular linear symbologies are supported. AutoPrint/Store capability, multiple scan averaging and sub-symbology choices are easily accessed through a six-button user interface. Analysis information appears immediately on a 4 line by 20-character alphanumeric liquid crystal display (LCD). A distinct audible tone and a series of five colored LED’s indicate whether a bar code is in or out of specification.
Quick Check 800 Series Model Description
- 800 – Symbologies Only
- 810 – Retail Specifications
- 820 – Healthcare Specifications
- 830 – Industrial Specification
- 850 – All Specifications
If needed, a detailed hard copy printout can be produced from the Quick Check 820 using an optional direct thermal or thermal transfer printer.
If needed, inspection data can transferred to any Windows PC. Once transferred the inspection data can be saved or printed to any standard Window printer.
The Quick Check 820 series meets the International Organization for Standardization’s “Bar Code Print Quality Test Specification (ISO 15416), the American National Standard Institute’s “Guideline for Bar Code Quality’ (ANSI X3.182-1990), the Uniform Code Council (UCC), and the CEN specifications regarding the decodability calculation method. It does NOT meet the International Organization for Standardization’s “Bar Code Verifier Conformance Specification” (ISO 15426-1), since only one parameter is tested.
This equipment and its documentation were developed to fit into your company’s existing ISO 9000/9001/9002 policies and procedures.
