RJS Inspector 4000 (3,6,10,20 Mil Apertures) Linear Bar Code Verifier

$2,745.00 $2,196.00

The original ISO/ANSI verifier from RJS

A Inspector 4000 scan head is the industry’s most flexible ISO/ANSI method verifier. Key features include a patented Auto-Optic scan head that allows for eight optical arrangements set-able via menu selections for four aperture sizes and two wavelengths of light. Repeatability between units is outstanding, making the Inspector 4000 an ideal choice for a standardized company-wide ISO/ANSI method verifier.

Three Auto-Optic scan head versions are available; 3, 6, 10, 20 mil, 3, 5, 10, 20 mil or 3, 5, 6, 10, 20 aperture choices. All versions provide red (660 nm) and infra-red (925nm) light wavelength selections.

SKU: RJS-I4000-6mil.

Product Description

The original ISO/ANSI verifier from RJS

A Inspector 4000 scan head is the industry’s most flexible ISO/ANSI method verifier. Key features include a patented Auto-Optic scan head that allows for eight optical arrangements set-able via menu selections for four aperture sizes and two wavelengths of light. Repeatability between units is outstanding, making the Inspector 4000 an ideal choice for a standardized company-wide ISO/ANSI method verifier.

Features

  • Multiple apertures (3, 6, 10, and 20 mil) and light wavelengths (660nm or 925nm) – set via menu selections
  • Traceable to NIST (National Institute of Standards and Technology)
  • Follows the ISO15416 and ANSI X3.182 Bar Code Inspection Method
  • Conforms to ISO15426-1 Bar Code Verifier Specification
  • Auto-discriminates between all popular symbologies
  • Bidirectional scanning
  • Multiple scan averaging
  • Traditional analysis also provided

This truly unique and powerful instrument is also easy to use. All the popular linear symbologies are supported. Store and print capability, multiple scan averaging and sub-symbology choices are easily accessed through a simple four-button user interface. Analysis information appears immediately on a 32-character alphanumeric liquid crystal display (LCD). A distinct audible tone and a series of five colored LED’s indicate whether a bar code is in or out of specification.

In addition to the ISO/ANSI method parameters, traditional analysis parameters are provided on the LCD without a special mode setting.

ISO/ANSI Mode Operation

A Inspector 4000 scan head is the industry’s most flexible ISO/ANSI method verifier. Key features include a patented Auto-Optic scan head that allows for eight optical arrangements set-able via menu selections for four aperture sizes and two wavelengths of light. Repeatability between units is outstanding, making the Inspector 4000 an ideal choice for a standardized company-wide ISO/ANSI method verifier.

NOTE: This model is only recommended for existing Inspector 4000 applications or new applications involving Code 93 symbols. For all other new applications the Inspector D4000 with an Auto Optic option is recommended.

If needed, a detailed hard copy printout can be produced from the Inspector D4000 using an optional direct thermal or thermal transfer printer.

If needed, inspection data can transferred to any Windows PC. Once transferred the inspection data can be saved or printed to any standard Window printer.

The Inspector 4000 meets the International Organization for Standardization’s “Bar Code Print Quality Test Specification (ISO 15416), the American National Standard Institute’s “Guideline for Bar Code Quality’ (ANSI X3.182-1990), the Uniform Code Council (UCC), and the CEN specifications regarding verification methods and methodology. It also meets International Organization for Standardization’s “Bar Code Verifier Conformance Specification” (ISO 15426-1).

This equipment and its documentation were developed to fit into your company’s existing ISO 9000/9001/9002 policies and procedures.

Additional Information

Product Type:

Brand:

Price:

Status:

Code Width:

, , , , , , , , ,

Code Height:

, , , , , , ,

Capt. Method:

Calib. Plaque:

Re-certification:

Capture Area:

ISO/ANSI:

,

Report Types:

,

Wavelength:

,

Bar Code Type:

Scanner Type:

Aperture Sizes:

, , ,

Industry App:

, , , , , , ,

Symbology:

, , , , , , , , ,
