Bar Code Verification Equipment
RJS D4000 Auto Optic Calibration Plaque

RJS Replacement Inspector D4000 Series Auto Optic (3, 6, 10, and 20 Mil Apertures with Calibration Plaque)

$1,045.00 $888.25

The RJS Inspector D4000 Series Auto Optic replacement requires either a D4000 bar code verifier display or a Inspector 4000 bar code verifier display.

SKU: RJS-D4000-Auto Optic-6mil.

Product Description

The RJS Inspector D4000 Series Auto Optic (3, 6, 10, and 20 mil Aperture with Calibration Plaque) requires either a D4000 bar code verifier display or a Inspector 4000 bar code verifier display. When the Auto Optic head is replaced, the D4000 bar code verifier display or a Inspector bar code verifier display MUST be sent in to Auto ID Solutions. This is required because the two parts must be adjusted, calibrated, and re-certified as an entire system. The service work is included in the cost of the Auto Optic head and will be returned in a new box and with a three page Certificate of Calibration (which shows the NIST traceable standards used to certify the unit and the “As Left” values following calibration. All service work is performed with 24 hours of arrival at our facility. Please request a RMA number from: http://www.autoidsolutions.com/services/rma-request/

Additional Information

Product Type:

Bar Code Verifier Accessory

Brand:

RJS

Price:

$0 – $1999

Status:

New

Code Width:

Less than 1.0 in width, Less than 1.5 in width, Less than 2.5 in width, Less than 2.0 in width, Less than 3.0 in width, Less than 4.0 in width, Less than 4.5 in width, Less than 5.0 in width, Less than 6.0 in width, Greater than 7.5 in width

Code Height:

Less than 0.5 in tall, Less than 1.0 in tall, Less than 1.5 in tall, Less than 2.5 in tall, Greater than 2.5 in, Less than 2.0 in tall, Less than 0.25 in tall, Less than 0.125 in tall

Capt. Method:

Contact

Calib. Plaque:

Yes

Re-certification:

Every 12 Months

Capture Area:

Single Scan Line

ISO/ANSI:

Full, Traditional

Report Types:

Standalone Printer, Windows Software

Wavelength:

660nm (Red), 925nm (Infrared – invisible)

Bar Code Type:

Linear 1D Bar Codes

Scanner Type:

Portable

Aperture Sizes:

3 mils, 6 mils, 10 mils, 20 mils

Industry App:

AIAG, ANSI, CEN, GS1, HIBCC, ISO/IEC, MIL-STD-130M, TAPPI

Symbology:

Codabar, Code 128, Code 39, EAN/JAN-13, EAN/JAN-8, Interleaved 2 of 5 (ITF), ITF-14, UPC-A, UPC-E
