Webscan TruCheck 2D Direct Part Marking FlexHite Tower 34mm x 25.5mm

$8,495.00

Webscan TruCheck 2D Direct Part Marking FlexHite Tower 34mm x 25.5mm

SKU: WEB-2D-DPM-FLEX-TOWER.

Product Description

Adjust the working distance of this versatile verifier for any part. With its
field of view and ability to verify 1D and 2D symbols with X dimensions as small
as 7.5 mil the TruCheck DPM FlexHite Tower can handle your most demanding barcode
verification challenges. Not just for direct part marks: a choice of 45 degree
lighting for ISO 15415 or AIM DPM (30 or 45Q or 90) makes it perfect for virtually any
direct part marking application include dot-peen and laser etched UID symbols.

But that’s not all. The adjustable height of this system makes it perfect for
verifying bar codes, whether they are 1D or 2D, when they are recessed or
otherwise hard to reach with other verifiers. Bar codes on products up to 6 inches tall may be inspected Simply place your part under the
camera head, and adjust the height with the manual turn-wheel while the
software detects and inspects the bar code automatically!

Additional Information

Product Type:

Bar Code Verifier

Brand:

Webscan

Price:

$4500 or more

Status:

New

Code Width:

Less than 1.0 in width, Less than 1.5 in width, Less than 2.5 in width

Code Height:

Less than 0.5 in tall, Less than 1.0 in tall, Less than 1.5 in tall, Less than 2.0 in tall, Less than 0.25 in tall, Less than 0.125 in tall

Capt. Method:

Non-Contact

Calib. Plaque:

Yes

Capture Area:

Area Scan

ISO/ANSI:

Full

Report Types:

Windows Software

Wavelength:

660nm (Red)

Scanner Type:

PC

Bar Code Type:

2D Matrix Bar Codes, Composite Bar Codes, Linear 1D Bar Codes, Linear and 2D Matrix Codes

Operating System:

Windows 7, Windows 8, Windows Vista, Windows XP

Aperture Sizes:

3 mils, 5 mils, Variable

Industry App:

AIAG, ANSI, CEN, GS1, HIBCC, ISO/IEC, MIL-STD-130M, TAPPI

Symbology:

Aztec Code, Codabar, Code 128, Code 39, Code 93, Composite Code CC-A, Composite Code CC-B, Composite Code CC-C, DataBar expanded, DataBar limited, DataBar stacked, DataBar-14, Datamatrix, Datamatrix(ECC200), EAN/JAN-13, EAN/JAN-8, GS1-128, Interleaved 2 of 5 (ITF), ITF-14, MaxiCode, Micro QR Code, MicroPDF417, MSI Plessey, PDF417, Pharmacode – Italian, QR Code, UPC-A, UPC-E
