Axicon 12800 DPM Direct Parts Marking Verifier

Axicon 12800 Linear and 2D DPM Bar Code Verifier

$7,995.00

Premium accuracy verifier for Direct Part Marked (DPM) 2D bar codes

Axicon 12800 2D DPM Bar Code Verifier (1.0″ x 0.7″)

SKU: AXI-12800.

Product Description

Axicon 12800 2D DPM

Features:

  • For bar codes up to 1.0″ x 0.7″ (25mm x 18mm)
  • Features included to meet the requirements of 21 CFR Part
  • Variable Aperture (Minimum 3mil)
  • AI Data Content Checker
  • Conforms to ISO 15415, ISO 15426-2, ISO 16022 Bar Code Verifier Specifications

Additional Information

Product Type:

Bar Code Verifier

Brand:

Axicon

Price:

$4500 or more

Status:

New

Code Width:

Less than 1.0 in width

Code Height:

Less than 0.5 in tall, Less than 1.0 in tall

Capt. Method:

Contact

Calib. Plaque:

Yes

Re-certification:

Every 12 Months

Capture Area:

Area Scan

ISO/ANSI:

Full, Traditional

Report Types:

Windows Printer, Windows Software

Wavelength:

660nm (Red)

Bar Code Type:

2D Matrix Bar Codes, Linear 1D Bar Codes, Linear and 2D Matrix Codes

Scanner Type:

PC

Operating System:

Windows 7, Windows 8, Windows XP

Aperture Sizes:

3 mils, 5 mils, 6 mils, 10 mils, 20 mils, Variable

Industry App:

AIAG, ANSI, CEN, GS1, HIBCC, ISO/IEC, MIL-STD-130M

Symbology:

Aztec Code, DataBar expanded, DataBar limited, DataBar stacked, DataBar-14, Datamatrix, Datamatrix(ECC200), PDF417, Pharmacode – Laetus, Pharmacode – Italian, QR Code
