Webscan Rover Wide Angle Linear and 2D Bar Code Verifier

$5,995.00

The Webscan Rover 2D and Linear Bar Code Verifier is GS1 certificated for both Linear and 2D bar codes and is fully portable. No special training or experience is required–using this verifier is as simple as placing the bar code verifier over the bar code and pushing a button. NOTE: The field of view for this model is 3.00″ x 2.24″ (76.5mm x 57mm) with a minimum X dimension of 8 mil.

SKU: WEB-Rover-WA.
Mfg. Part #: TC-503

Product Description

The Webscan Rover 2D and Linear Bar Code Verifier is GS1 certificated for both Linear and 2D bar codes and is fully portable. No special training or experience is required–using this verifier is as simple as placing the bar code verifier over the bar code and pushing a button. Features of this unit include:

  • Simple image/bar code capture
  • Automatic bar code inspection of multiple bar codes at one time
  • Automated 10 scan average inspection
  • Extensive troubleshooting for print optimization
  • Full Pharmaceutical reporting and IQ/OQ audit trail conformance (optional)
  • Dimensional measurement reporting
  • Support of network database storage
  • Battery charger

The Rover inspects all of the ISO/ANSI parameters in compliance with ISO 15416 (linear), and ISO 15415 (2D), and more detailed analysis of the bar code is available with the press of a button. The analysis will be color coded to show exactly where the problem is within the bar code. Sections of the bar code can be analyzed to better determine how to solve the problem.

NOTE: The Rover meets the International Organization for Standardization’s (ISO) “Bar Code Print Quality Test Specification (ISO 15416 and 15415) and the American National Standard Institute’s “Guideline for Bar Code Quality’ (ANSI X3.182-1990). The Rover is in complinace with MIL-STD 130 (L through N), ISO 16022, ISO 18004, ISO 16023, ISO 24778, AIQG AS9132, and AIM DPM (only 45Q). It also meets International Organization for Standardization’s “Bar Code Verifier Conformance Specification” (ISO 15426-1 and ISO 15426-2). This equipment and its documentation were developed to fit into your company’s existing ISO 9000/9001/9002 policies and procedures.

Additional Information

Product Type:

Bar Code Verifier, Bar Code Verifier Software

Brand:

Webscan

Price:

$4500 or more

Status:

New

Code Width:

Less than 2.5 in width, Less than 2.0 in width, Less than 3.0 in width, Less than 4.0 in width

Code Height:

Less than 1.0 in tall, Less than 1.5 in tall, Less than 2.5 in tall, Less than 2.0 in tall

Capt. Method:

Non-Contact

Capture Area:

Area Scan

ISO/ANSI:

Full

Bar Code Type:

2D Matrix Bar Codes, Composite Bar Codes, Linear 1D Bar Codes, Linear and 2D Matrix Codes

Scanner Type:

PC

Operating System:

Windows 7, Windows 8, Windows Vista, Windows XP

Aperture Sizes:

3 mils, 5 mils, 6 mils, 8 mils, 10 mils, 20 mils, Variable

Industry App:

ANSI, CEN, GS1, ISO/IEC, MIL-STD-130M

Symbology:

Aztec Code, Codabar, Code 128, Code 39, Code 93, Composite Code CC-A, Composite Code CC-B, Composite Code CC-C, DataBar expanded, DataBar limited, DataBar stacked, DataBar-14, Datamatrix, Datamatrix(ECC200), EAN/JAN-13, EAN/JAN-8, GS1-128, Interleaved 2 of 5 (ITF), ITF-14, MaxiCode, Micro QR Code, MicroPDF417, MSI Plessey, PDF417, Pharmacode – Laetus, Pharmacode – Italian, QR Code, UPC-A, UPC-E
