Axicon 15500

Axicon 15500 Linear and 2D Bar Code Verifier

$7,495.00

Premium accuracy verifier for 2D bar codes Axicon 15500 2D Bar Code Verifier (3.74″ x 2.75″)

SKU: AXI-15500.

Product Description

Axicon 15500 2D Bar Code Verifier

Features:

  • For bar codes up to 3.74″ x 2.75″ (90mm x 70mm)
  • Three operating positions
  • USB powered
  • Variable Aperture (Minimum 7mil)
  • AI Data Content Checker
  • Conforms to ISO 15415, ISO 15426-2, ISO 16022 Bar Code Verifier Specifications

Additional Information

Product Type:

Bar Code Verifier, Bar Code Verifier Software

Brand:

Axicon

Price:

$4500 or more

Status:

New

Code Width:

Less than 1.0 in width, Less than 2.0 in width, Less than 3.0 in width, Less than 4.0 in width

Code Height:

Less than 1.0 in tall, Less than 1.5 in tall, Less than 2.5 in tall, Greater than 2.5 in

Capt. Method:

Contact

Calib. Plaque:

Yes

Re-certification:

Every 12 Months

Capture Area:

Area Scan

ISO/ANSI:

Full, Traditional

Report Types:

Windows Printer, Windows Software

Wavelength:

660nm (Red)

Bar Code Type:

2D Matrix Bar Codes, Linear 1D Bar Codes, Linear and 2D Matrix Codes

Scanner Type:

PC

Operating System:

Windows 10, Windows 7, Windows 8

Aperture Sizes:

16 mils, 5 mils, 6 mils, 8 mils, 10 mils, 20 mils, Variable

Industry App:

AIAG, ANSI, CEN, GS1, HIBCC, ISO/IEC, MIL-STD-130M

Symbology:

Aztec Code, Codabar, Code 128, Code 39, Code 93, DataBar expanded, DataBar limited, DataBar stacked, DataBar-14, Datamatrix, Datamatrix(ECC200), EAN/JAN-13, EAN/JAN-8, GS1-128, Interleaved 2 of 5 (ITF), ITF-14, MSI Plessey, PDF417, Pharmacode – Laetus, Pharmacode – Italian, QR Code, UPC-A, UPC-E
