Bar Code Verification Equipment
Axicon PV1000 Portable DisplayAxicon PC7015 Linear Bar Code Verifier with 7.68 Inch Inspection WidthAxicon PC7015 PC7000 PC 7000 7015 Case Manual

Axicon PV1000 plus PC7015 Linear Bar Code Verifier (7.68″ Inspection Width)

$5,690.00

Axicon PV1000 plus Axicon 7015 Linear Bar Code Verifier (7.68″ Inspection Width)

Premium accuracy verifier for medium- to large-sized bar codes

SKU: AXI-PV7015.

Product Description

Axicon 7015 Linear Bar Code Verifier

Features:

  • Push button bar code capture
  • Automatic variable aperture (10, 20 mil)
  • Inspection area up to 7.68″ (195mm) including quiet zones
  • USB or serial connection
  • Free lifetime software upgrades

PV-1072 Portable Display for all Axicon verifiers

Features:

  • For use with any Axicon Verifier
  • ISO/ANSI Verification Standards
  • User friendly interface
  • Save scans for later retrieval
  • Free lifetime software upgrades





Additional Information

Product Type:

Bar Code Verifier

Brand:

Axicon

Price:

$2000 – $2999

Status:

New

Code Width:

Less than 1.0 in width, Less than 1.5 in width, Less than 2.5 in width, Less than 2.0 in width, Less than 3.0 in width, Less than 4.0 in width, Less than 4.5 in width, Less than 5.0 in width, Less than 6.0 in width

Code Height:

Less than 0.5 in tall, Less than 1.0 in tall, Less than 1.5 in tall, Less than 2.5 in tall, Greater than 2.5 in, Less than 2.0 in tall, Less than 0.25 in tall, Less than 0.125 in tall

Capt. Method:

Contact

Calib. Plaque:

Yes

Re-certification:

Every 12 Months

Capture Area:

Single Scan Line

ISO/ANSI:

Full, Traditional

Report Types:

Windows Printer

Wavelength:

660nm (Red)

Bar Code Type:

Linear 1D Bar Codes

Scanner Type:

Mac, PC

Aperture Sizes:

8 mils, 10 mils, 20 mils

Industry App:

AIAG, ANSI, CEN, GS1, HIBCC, ISO/IEC, MIL-STD-130M, TAPPI

Symbology:

Codabar, Code 128, Code 39, Code 93, DataBar expanded, DataBar limited, DataBar stacked, DataBar-14, EAN/JAN-13, EAN/JAN-8, GS1-128, Interleaved 2 of 5 (ITF), ITF-14, UPC-A, UPC-E
